9 Digits Alphanumeric Fluorescent Display Module 9MS09SS1 2 Wire Serial Interface
  • 9 Digits Alphanumeric Fluorescent Display Module 9MS09SS1 2 Wire Serial Interface
  • 9 Digits Alphanumeric Fluorescent Display Module 9MS09SS1 2 Wire Serial Interface
  • 9 Digits Alphanumeric Fluorescent Display Module 9MS09SS1 2 Wire Serial Interface

9 Digits Alphanumeric Fluorescent Display Module 9MS09SS1 2 Wire Serial Interface

Place of Origin China
Brand Name SSOT
Certification ISO9001
Model Number 9MS09SS1
Product Details
14 Segment Alpha Mumeric & Decimal Point, 9 Digits
2 Wire Serial Interface
PCB Size:
124.5*33 MM
Display Area:
88*13.5 MM
Blue-green (x:0.250; Y:0.439)
700 CD
Operating Temperature:
0 ~ 70 ℃
Operating Humidity:
30 ~ 85%
Storage Temperature:
-40 ~ 85 ℃
Storage Humidity:
30 ~ 90%
High Light:

vacuum fluorescent display


vacuum tube display


Serial Interface Alphanumeric Fluorescent Display

Payment & Shipping Terms
Minimum Order Quantity
Packaging Details
Carton box L474 * W379 * H416
Delivery Time
28~42 days
Payment Terms
TT; Paypal
Supply Ability
10,000 pcs / month
Product Description

9 digits Alphanumeric Vacuum Fluorescent Display(VFD) module 9MS09SS1




  • Simple connection to the host system data bus via two-wired serial interface
  • 14 segments alphamumeric & decimal point, 9 digits
  • Since a DC/DC converter is used, only +5VDC power source is required to operate the module
  • One chip controller offers integral 64×16 bit programmable logic array, low power consumption and high reliability in services
  • 32 brightness levels can be selected by brightness control command
  • High quality blue-green(505 nm) vacuum fluorescent display provides an attractive and readable medium. Other colors can be achieved by simple wavelength filters
  • Characters are provided in an attractive 14-segment starburst format​




  • Scales, ECR, POS, ATM, medical, communication, elevator
  • Measuring equipment display, test equipment display, instrument display
  • Information boards in hospitals, banks, complexes,buildings, stations, etc.



Packaging and delivery:

  • Antistatic bag + carton box
  • Sea freight or air freight
  • Express: Fedex, DHL etc...




  • Self-luminous, high brightness and contrast ratio, wide viewing angle
  • Multi color variety
  • Long service time and high reliability
  • Simple interface and high speed data write in capability, quick response time



About us

Our company is located in Shanghai China, and specialized in the designing and manufacturing VFD display, LED display

Our products are widely used as industrial control display, Medical instruments display, POS customer display and peripheral devices, Cash Drawer display, automotive display, Set-Top-Box display, DC Power display, Scale display, meters display, Programmable Keyboards display etc.

Our customers are widely spread at North America, Europe, Japan, Korea, South-east Asia, India, Middle East, Australia, South America, etc.

With the goals of quality and adaptability in the market competition, as well as the ability of developing new products in short periods. we welcome interested companies worldwide to inquire our products

We are looking forward to cooperation with you in the near future.







Is your parts new and original?

Answer: Yes, our parts could accept any kinds of testing, if there is any quality problem we will take responsibility.

What is your warranty?

Answer: Within one year after package have been received.

How to pay the order?

Answer: We could accept TT, Escrow, Paypal. After the order have been confirmed the invoice will be sent for reference. Then make payment as the way you like, as soon as the payment have been confirmed, we will arrange shipment within 3 days.

Quality problems

Answer: If there is any quality problem or question, we could offer technical support or return service.

What is your lead time?

Answer: 6 weeks; For in-stock products. Lead time is 3 days after payment have been confirmed.

6. May I have a sample for testing?

Answer: Yes, only to pay shipping cost, free samples would be sent for testing.

7. Shipping:
